KAABO MANTIS 10 SWISS EDITION
The KAABO Mantis 10 is an electric scooter that is currently in great demand. It is characterized by a simple but very sporty design. We offer you the last version with a bigger battery and a more powerful motor!
1. Technical characteristics:
The KAABO Mantis Lite electric scooter has an 500 watt motor in the rear wheel, which makes it a drive. The maximum speed of this electric scooter is 20 km/h. It is advisable not to exceed a load weight of 120 kg on this electric scooter. The lithium-ion battery of the KAABO Mantis Lite develops an output of 48 V / 18.2 Ah, which enables it to achieve a very comfortable range of almost 50 km (value tested on the road with a driver of 75 kg on a flat track at an outside temperature of 20 ° C).
A non-road legal version 800 Watts / 45Km/h is also available.
The battery is located in the running board under the driver's feet in order to achieve maximum weight close to the ground and to optimize the road situation. This electric scooter is equipped with 10-inch pneumatic tires, hydraulic disc brakes and front and rear suspensions. The net weight of the KAABO Mantis Lite electric scooter is 21.8 kg.
2. Operating instructions:
If you click on the following link, you will see the complete KAABO Mantis 10 user manual that is supplied with the electric scooter: Operating instructions KAABO Mantis Lite
How to assemble the electric scooter upon delivery:
We remind you that you can also pick up your KAABO Mantis 10 electric scooter in on of our shops in Switzerland. We are happy to take the time to explain how it works and give you tips on driving. If you receive your electric scooter directly at home, all you have to do is screw the handlebar to the handlebar with the four screws using the tool kit included in the scope of delivery, and fully charge the battery before using it for the first time.
How to unfold / close the electric scooter:
The KAABO Mantis Lite has a double clamping system at the base of the handlebar to avoid as much play in the handlebars as possible.
You need to lower the clamp ring and then flip down the two latches. With the two screws you can adjust the strength of the latch.
How to start the electric scooter:
To switch on the KAABO Mantis Lite electric scooter, press the "Power" button for 3 seconds. The display will light up immediately.
Driving speed, battery level, mileage and speed are shown on the display. Depending on the speed that you select by pressing the white circle, the electric scooter has different types of acceleration. However, it's more fun to put in a high gear and then adjust the speed with the throttle while driving.
3. Operating instructions:
To switch off the electric scooter, press and hold the "Power" button for three seconds. With the "Mode" button you can change the display from mileage to odometer or to the battery voltage.
If you hold down the "Mode" button for three seconds, you will enter the submenu of the electric scooter:
P0 corresponds to the size of the wheel. For the KAABO Mantis Lite, choose number 10 for 10 inches.
P1 corresponds to the voltage of the controller. On the KAABO Mantis Lite there is a 48 volt controller.
P2 is the number of magnets in the motor, i.e. H. 15.
P3 must stay at 0 With
P4 you can switch from kilometers to miles.
P5 is the start security. If you select 0, the scooter starts as soon as you operate the throttle. If you choose 1, you will need to physically propel the scooter before accelerating. The idea is to avoid accidentally starting the electric scooter.
P6 corresponds to "Tempomat". If you drive at a constant speed for 5 seconds, the scooter will stop at that speed until you apply the brakes. It is recommended to disable this feature.
P7 is the start acceleration type. You can adjust the engine power when accelerating. The higher the number (between 0 and 5), the smoother the acceleration.
With P8 you can limit the motor output. By selecting 5, you are limiting the speed of the scooter very significantly.
P9 is the battery saving mode. The higher the number, the more gently the scooter accelerates and limits the top speed.
PA stands for EBS or electronic brake. In mode 0 you have no electronic braking.
With Pb you can adjust the brightness of the LCD screen of the display.
PC is the time in minutes from which the KAABO Mantis Lite electric scooter goes into sleep mode.
With Pd you can activate or deactivate ABS.
4. Maintenance battery:
In order to extend the service life of a lithium-ion battery, it is strongly recommended to keep the charge level of the battery between about 80% and 100%. Do not charge the battery when it is already full (do not leave it to charge overnight) and never discharge the battery completely.
When you charge your eScooter, it is essential to connect the charger to the mains before you connect the electric scooter. After using the scooter, wait 20 minutes before charging the battery to allow it to cool down.
If you store the electric scooter for several months, it is important not to fully charge the battery but to store the electric scooter with a charge level of approx. 60%. Always store the electric scooter in a place protected from moisture and at a temperature of at least 5 ° C.
5. Maintenance and care:
General maintenance of the electric scooter: It is important to check the tight fit of the screws very regularly, but at least once a month, as an eScooter is exposed to a lot of vibrations while driving. With the KAABO Mantis Lite you also get a tool set. Remember to check the tire pressure regularly. With this model it is advisable to inflate the tires to a pressure of 50 PSI (approx. 3.5 bar). Your electric scooter is cleaned with a damp cloth.
6. Accessories:
Below is a list of important accessories:
Masterlock CUFFS has a fastening system can be attached safely to the steering column of your KAABO Mantis.
INOKIM handlebar bag can be attached directly to the handlebar and allows you to easily take all the items you need with you.
